Rango de Fijación Ø127 a Ø483mm
F-24 steel, hot-dip galvanized
| Poste - Ø Máx | Largo total | Nº Agujeros | Rotura (Kgf) | Peso (Aprox.) (Kg) | ||
| Pulg | mm | |||||
| BAP -1 | 5" | 127 | 450 | 11 | 500 | 0.310 |
| BAP -2 | 10” | 254 | 813 | 22 | 1500 | 0.440 |
| BAP -3 | 15” | 381 | 1176 | 33 | 1500 | 0.560 |
| BAP -4 | 19” | 483 | 1540 | 44 | 1500 | 0.690 |
